HYDRIM M2 G4 Installation Instructions
Connect water feed pipes to machine and relevant services:
Water feed requirements:
Hot water feed with G ¾" shut off valve
(washing machine fitting)
• Maximum distance from installation less
than 1.50 meters
• Pressure between 2 and 5 bar
Cold water feed with G ¾" shut off valve
(washing machine fitting)
• Maximum distance from installation less
than 1.50 meters
• Pressure between 2 and 5 bar
Reverse Osmosis water feed with G ¾"
shut off valve (washing machine fitting)
• Maximum distance from installation less
than 1.50 meters
• Pressure between 2 and 5 bar
Connecting the water inlet hoses (see diagram):
Connect the hot water hose (red) to the hot water inlet valve on the HYDRIM
(indicated by a red dot) and the cold water hose (blue) to the cold water inlet valve on the
HYDRIM (indicated by a blue dot). Treated water from a reverse osmosis system can be
connected to the R/O inlet. If fitted with treated water, the software must be adjusted to
enable the function of the R/O inlet. The end of the hose with the gasket and the screen
should attach to the water supply connector. Make sure that the inlet valves are free of de-
bris.
NOTE 1 - If hot water feed is not available then it must be possible to attach a 'Y' fitting to
the cold water feed valve so that both machine pipes can be connected to the cold
supply. The machine will not work with only one supply attached as it requires pressure
in both the hot and cold water supplies to activate the feed pressure switches. If R/O
water is not enabled, the R/O supply does NOT need an attachment. Please note that
cold fill only will increase cycle times.
NOTE 2 – Water feeds should be adjacent to the machine and not behind it so that the shut
off valves may be accessed in case emergency isolation is required and to ensure unit can
be inserted fully under the work surface.
