HYDRIM M2 G4 Installation Instructions
Set up unit as follows:
• Unpack unit and remove all restraining ties
• Locate unit in approximate position
NOTE 1 - Do not move the HYDRIM M2 G4 into place by maneuvering the open wash
chamber door. This may cause the door to become misaligned and can cause leakage.

Unit overview

Upper Load
Upper Trolley
Lower Load
Lower Trolley
Rear of Unit
Cover
Basket
(Optional)
Basket
(Optional)
Door
Power connector
Cold Water
Inlet Hose
RO Water
Inlet Hose
Fuse Holder
Hot Water
Inlet Hose
Page 6
USB
Port
Touch
Screen
On/Off
Switch
Chemical
Drawer
Kickplate
Ethernet Connector
Printer Connector
Drain Hose
