CoreTech Encoder
Encoders with stator coupling for blind
hollow shaft (Figure 5)
Lock the drive shaft on the application side.
Loosen the socket-head screw (1) on the
clamping ring (2).
Push the encoder and collet onto the drive
shaft. Take note of installation Figure (6).
Fix the torque support (3) with 4 M3 screws
(4) and washers.
Firmly tighten the socket-head screw (1) on
the clamping ring (2).
Make the electrical connections with the
voltage switched off. Switch on the voltage
and check the functioning of the encoder.
Issue 01 / 06
The right to make technical changes is reserved
•
Encoders with stator coupling for through
hollow shaft (Figure 7)
Lock the drive shaft on the application side.
Loosen the socket-head screw (1) on the
clamping ring (2).
Push the encoder and collet onto the drive
shaft. Take note of installation Figure (8).
Fix the torque support (3) with 4 M3 screws
(4) and washers.
Firmly tighten the socket-head screw (1) on
the clamping ring (2).
Make the electrical connections with the
voltage switched off. Switch on the voltage
and check the functioning of the encoder.
GB
915 040 002 816
