SICK CoreTech DRS60 Montageanleitung Seite 23

CoreTech Encoder Singleturn Absolute, SSI ARS60
View of the connector
fitted to the encoder
body
Signal
GND
Data (+)
Clock (+)
N. C.
cw / ccw
N. C.
N. C.
U
s
SET
Data (–)
Clock (–)
N. C.
12-pin
connector
1
2
3
4
5
6
7
8
9
10
11
12
11-core
cable outlet
blue
white
yellow
–
pink
–
–
red
orange
brown
violet
–
