CoreTech Encoder Incremental DRS60/DRS61
View of the connector
fitted to the encoder
body
PIN Signal
10 - 32 Volt
1 B
2 Sense (+)
3 Z
4 Z
5 A
6 A
7 N. C.
8 B
9 Screen
10 GND
11 Sense (–)
12 U
s
Signal
5 Volt cable outlet
B
Sense (+)
Z
Z
A
A
N. C.
B
Screen
GND
Sense (–)
U
s
11-core
black
grey
lilac
yellow
white
brown
orange
pink
blue
green
red
