References marked on instrument or in
instruction manual:
Warning of a potential danger, comply with in-
struction manual.
Reference. Please use utmost attention.
Caution! Dangerous voltage. Danger of electri-
cal shock.
Continuous double or reinforced insulation
complies with category II.
Conformity symbol, the instrument complies
with the valid directives. It complies with the
EMC Directive (89/336/EEC), Standards EN
50081-1and EN 50082-1 are fulfilled. It also
complies with the Low Voltage Directive
(73/23/EEC), Standard EN 61010-1 is fulfilled.
The instruction manual contains information
and references, necessary for safe opera-
tion and maintenance of the instrument.
Prior to using the instrument (commissioning
/ assembly) the user is kindly requested to
thoroughly read the instruction manual and
comply with it in all sections.
Failure to read the instruction manual or to
comply with the warnings and references
contained herein can result in serious bodi-
ly injury or instrument damage.

1.0 Introduction / Scope of Supply

You have acquired a high standard measurement in-
strument supplied by the company Ch. BEHA GmbH
which is able to perform reproducible measure-
ments over a very long time period. The company
Ch. BEHA GmbH is a member of the world-wide op-
erating BEHA group. The head office of the BEHA
group is located in Glottertal/Schwarzwald, togeth-
er with the technological centre. The BEHA group is
a leading enterprise for test and measurement in-
struments.
Introduction / Scope of Supply
The UNITEST Echometers are universally usable
cable length measurement instruments. They have
been built in compliance with the most recent pre-
scriptions and gurantee safe and reliable measure-
ments. The UNITEST Echometers are a valuable
support for trade and industry for tally measure-
ments, inventories, and residual length measure-
ments.
The instruments have the following characteris-
tics:
• Echometer for easy and time efficient measure-
ment of cable lengths in trade, industry, utility
companies, and specialist electronic stores.
• Only one cable end is required. Thus, conductors
already installed or cable drums can be measured,
thus saving time.
• 58 fixed, pre-programmed measurement ranges
representing the most common cable cross sec-
tions
• 87 variable measurement ranges, individually
programmable by the user to measure customer
specific conductor and cable types
• Detecting single or multi-wire conductor inter-
ruptions or short-circuits for trouble shooting
• Cable and conductor length measurement up to
approx. 2000 m (depending on the type of con-
ductor)
• Internal data memory to save 500 measurements
for inventories, tally measurements, cable return
measurements, etc.
• RS232 interface for transfer and further PC pro-
cessing of measurement data
• Cumulative memory to measure and cumulate
several cable rings of the same type of conductor,
saving time and money
• Additional resistance measurement up to 2000
Ohm and acoustic continuity test
• Display light for better visibility while working in
badly illuminated environments, such as storage
areas
• Automatic power off
