Introduction
The POWER PEAK 3 SPORT is designed for charging and discharging NICD and NIMH
batteries consisting of 1 to 10 cells.
The unit provides the following functions: CHARGE, DISCHARGE, DISCHARGE-BEFORE-
CHARGE AND triple DISCHARGE-BEFORE-CHARGE.
Safety notes
-
If the charger is not to be used for a protracted period, disconnect it from the power
source and remove any battery packs connected to it.
-
Be sure to keep the cooling slots unobstructed to provide good air circulation - don't
stand the charger on a carpet or felt surface.
-
Do not set up the charger and batteries on a flammable surface, and never leave the
unit operating unsupervised.
-
Protect the unit from damp.
-
Take care to maintain correct polarity at all connections and outputs. If you connect a
pack with reversed polarity the fuse will blow.
-
Avoid short-circuits.
-
Don't subject the charger to direct sunshine, and do not cover it.
-
Do not charge batteries which are already hot; allow them to cool down to ambient tem-
perature before recharging.
-
Use only packs of fast-charge cells which have been properly balanced (equal state of
charge).
-
Packs must consist of cells of the same make, type and capacity.
-
Do not wire two packs together in parallel for charging.
-
The unit is only suitable for use with rechargeable batteries.
-
Set charge currents within the maximum rated capacity of the cables and connectors
attached to the battery pack.
-
Never connect any charger output to the input.
Specification
Operating voltage:
Current drain:
Nominal battery voltage:
Charge current:
Automatic charge termination: Delta Peak process
Trickle charge current:
Discharge current:
Discharge termination:
Max. discharge power:
Protective functions:
Fuse:
Dimensions:
Operating instructions
POWER PEAK 3 Sport
approx. 11 V ... 15 V DC
12 V lead-acid battery or a powerful well stabilised mains
PSU (do not use a car battery charger!)
max. approx. 10 A
1.2 V ... 12.0 V (1 ... 10 NICD / NIMH cells)
0.1 A ... 6.5 A up to 15 V, 0.1 A ... 4.0 A over 15 V
approx. 80 mA
0.1 A ... 3.0 A
automatic, at approx. 0.8 V / cell
approx. 25 W
Polarity protection at input and output, short-circuit protec
tion on output, overheating protection,
low voltage protection
7.6 A car fuse
approx. 100 x 140 x 52 mm
8
Order No.
8425
