ENERGY 03.71 Wh C
SET CHA. 4.00 A
SET DIS. 3.00 A
NiCD BATTERY
INPUT 11.95 V
OUTPUT 11.95 V
OUTPUT +1.50 A
"C" indicates CHARGING; you may also see the following letters: R = READY, D =
DISCHARGING, D/C = DISC/CHAR according to the current state of the charger (active
state flashes). The screen may also display N = NO BATTERY.
All displayed parameters are erased when you connect a battery pack, or switch from
Discharge to Charge or vice versa; at the same time the stored capacity values move back
one step (from M1 to M2 etc.).
Operating modes
The following screen displays can be selected using the MODE button. In each case the
corresponding operating mode is activated.
CHARGING
DISCHARGING
DISC - CHAR 1 TIME
DISC - CHAR 3 TIME
Operating instructions
POWER PEAK 3 Sport
Display of charged-in or discharged energy
Setting the charge current
C
Setting the discharge current
C
Setting the battery type (NICD or NIMH)
C
Display of input voltage
C
Display of battery pack voltage
C
Display of charge current (+) or discharge current (-)
C
Activates the charge process
Activates the discharge process
Activates charge before discharge
Activates triple discharge before charge
11
