Teileliste - Taurus Ergometer UB10.5 Pro Montage- Und Bedienungsanleitung

8.3

Teileliste

Nr. Bezeichnung (ENG)
1 Main Frame
2 Front Stabilizer
3 Rear Stabilizer
4 Seat Post
5 Upright Post
6 Handlebar
7 Left Cover
8 Right Cover
9 Upper Chain Cover
10 Crank Cover
11 Left Pedal
12 Right Pedal
13 Belt (762J8)
14 Belt (1092J8)
15 Pulley (235)
16 Magnet
17 Pulley (120)
18 EndCaps
19 Leveler
20 Transportation Wheels
21 Seat
22 Seat Lower Case
23 Adjustment Bar
24 Slider
25 Seat Post Sleeve
26 Upper Foam Grip
27 Foam Grip
28 Hand Wrist Pad
29 Pulse Sensor Top Housing
30 Pulse Sensor Bottom Housing
31 Console
36
Anz. Nr. Bezeichnung (ENG)
1 32 Battery Door
1 33 Console Bracket
1 34 Upper Handlebar Decoration Cover
1 35 Lower Handlebar Decoration Cover
1 36 Accessory Tray Support Pad
1 37 Accessory Tray
1 38 Left Upright Post Sleeve
1 39 Right Upright Post Sleeve
1 40 Front Aluminum Upright Cover
2 41 Rear Aluminum Upright Cover
1 42 Air Pressure Bar
1 43 Seat Adjustment Lever
1 44 Fixed Stand
1 45 Spacer
1 46 Cable
1 47 Cable Spring
1 48 Roller Axle
4 49 Stand Spring
4 50 Spacer Stand
2 51 Arc Washer
1 52 Resistor
1 53 Controller
1 54 Right Mounting Plate
1 55 Left Mounting Plate
1 56 Generator
2 57 Adaptor Bracket
2 58 One Way Pulley (51)
2 59 One Way Bearing(2520)
2 60 Axle
2 61 Crank Shaft
1 62 Left Crank
Anz.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
UB10.5 Pro
