Taurus Ergometer UB10.5 Pro Montage- Und Bedienungsanleitung Seite 37

Nr. Bezeichnung (ENG)
63 Right Crank
64 Idler Arm
65 Axle Connection Cap
66 Idler Wheel Spacer
67 Idler Spring
68 Bearing (6004)
69 Square Key (6x6x15mm)
70 E-Ring
71 C-Ring
72 Eye Bolt
73 Tension Bracket
74 Lock Washer (M8)
75 Washer (8×23×2.0t)
76 Washer (8×38×2.0t)
77 Washer (10×23×2.0t)
78 Washer (10.6×60×2.0t)
79 Washer (17×25×1.0t)
80 Washer (18.3×25×1.0t)
81 Washer (6x13x1.0t)
82 Washer (21×30×1.0t)
83 Screw (M3×10mm)
84 Screw (M3×25mm)
85 Screw (M4×20mm)
86 Screw (M5×18mm)
87 Bolt (M5×p0.8×15mm)
88 Bolt (M5×p0.8×30mm)
89 Bolt (M5×p0.8×75mm)
90 Bolt (M6×p1.0×10mm)
91 Bolt (M6×p1.0×20mm)
92 Bolt (M8×p1.25×55mm)
93 Bolt (M10×p1.5×30mm)
94 Bolt (M8×p1.25×10mm)
Anz. Nr. Bezeichnung (ENG)
1 95 Bolt (M8×p1.25×16mm)
1 96 Bolt (M10×p1.5×45mm)
1 97 Bolt (M8×p1.25×15mm)
1 98 Bolt (M8×p1.25×15mm)
1 99 Bolt (M8×p1.25×65mm)
8 100 Bolt (M8×p1.25×80mm)
101 Bolt (M10×p1.5×25mm)
1
1 102 Bolt (M6×p1.0×12mm)
2 103 Bolt (L=35mm)
4 104 Nut (M6×p1.0)
2 105 Nut (M8×p1.25)
15 106 Nylon Nut (M6×p1.0)
2 107 Thin Nylon Nut (M8×p1.25)
4 108 Nylon Nut (M8×p1.25)
2 109 Nylon Nut (M10×p1.5)
1 110 Flange Nut (M10×p1.25)
1 111 Nut (M10×p1.25)
1 112 Upper Connection Wire
2 113 Middle Connection Wire
2 114 Lower Connection Wire
1 115 Lock washer (M6)
4 116 Bolt (M6xp1.0x12mm)
8 117 Sensor Wire & Stand
24 118 Upper Pulse Sensor Wire
18 119 Middle Pulse Sensor Wire
2 120 Lower Pulse Sensor Wire
2 121 Generator Connection Wire
4 122 TFT Battery Connection Wire
4 123 TFT Battery
2 124 TFT Battery Bracket
1 125 Spacer (4.6mm)
5 126 Spacer (36mm)
Anz.
5
1
4
1
4
4
2
4
2
3
3
2
8
6
4
1
1
1
1
1
2
2
1
1
1
2
2
1
1
2
1
1
37
