Taurus Racer Pro Montage- Und Bedienungsanleitung Seite 38

8.2 Teileliste
Nr. Bezeichnung (ENG)
1 Main frame
2 Rear stabilizer
3 Adjustable wheel
4 Front stabilizer
5 Oval Cap
6 Allen boltM8*1.25*35L
7 ScrewM8x1.25x20L
9 Spring washer
10L Back chain cover(left)
10R Back chain cover(right)
11 Round cycle for chain
cover(1)
12 Round cycle for chain
cover(2)
13 Seat post
14 Inner insert
15 Inner insert(2)
16 Flat washer
17 Front post
18 L knob
19 Cap(1)
20 Cap(2)
21 Bearing#6004-2RS
22 Waved washer
23 Handlebar adjustable tube
24 C-clip(D22.5*D18.5*1.2T)
25L Chain cover supporting
tube(left)
25R Chain cover supporting
tube(right)
26 Crank axle
27 Pulley
38
Hrst. Teilenummer
849S0-3-1000-J3
849S0-3-2112-J1
76100-6-2174-B0 D50*M10*1.5
849S0-3-2100-J1
849S0-6-2190-B0 125.5*54.6*88.6L
50308-5-0035-F0 M8*1.25*35L
25600-6-3191-F0 M8x1.25x20L
55108-2-1520-FA D15.4xD8.2x2T
849S0-6-4512-B0 D474*52.7
849S0-6-4513-B0 D474*55.2
849S0-6-4510-B0 96*46*9.2
849S0-6-4511-B0 89*50.2*9.2
849S0-3-2200-AF1
849S0-6-1071-B0 21.5*80*200L
849S0-6-1093-B0 20*80*200L
55108-1-1612-FA D16*D8.5*1.2T
849S0-3-2000-AF1
52710-2-0020-RA M10*20L
849S0-6-2286-B0 55.7*29.4*18
849S0-6-2287-B0 56.6*26.4*18
58006-6-1040-01 #6004-2RS(C0)
55120-5-2705-DA D27*D20.3*0.5T
849S0-6-2018-AF2 56.3*30*210L
55519-1-2312-DA D22.5*D18.5*1.2T
849S0-6-3111-J0 20*40*1.5T*50L
849S0-6-3112-J0 38*38*1.5T*50L
849S0-6-2702-D1 D20*128L
58008-6-1041-00 D300*25.5*2.8T
Spezifi kation
Racer Pro
Anz.
1
1
4
1
4
6
8
6
1
1
1
1
1
2
2
6
1
2
4
4
2
1
1
2
1
1
1
1
