Washer (fastening bolt vice rear jaw)
29
Fastening bolt (vice rear jaw)
30
Hexagonal socket head screw (fastening of
31
mounting piece)
Base plate
32
Saddle
33
Washer (hexagonal socket head screw saddle)
34
Hexagonal socket head screw (fastening of
35
saddle)
Mount
36
Clip
37
Rear mounting piece
38
Nut (mounting bolt guard mount)
39
Mounting bolt (guard mount)
40
Vice
41
©

Included items

Check that all the items and accessories are pre-
sent and that the product and its all parts have no
defects immediately after unpacking. Do not as-
semble the product if any of the included items list-
ed below are missing.
1 x Base plate
1 x Saddle
2 x Washers (hexagonal socket head screw saddle)
2 x Hexagonal socket head screws (fastening of
saddle)
2 x Hexagonal socket head screws (fastening of
mounting pieces)
1 x Mount
1 x Adjustment screw with rubber buffer (long)
2 x Mounting bolts M10 (angle grinder)
2 x Mounting bolts M8 (angle grinder)
2 x Mounting bolts M6 (angle grinder)
2 x Nuts (mounting bolts M10 angle grinder)
2 x Nuts (mounting bolts M8 angle grinder)
2 x Nuts (mounting bolts M6 angle grinder)
1 x Handle
1 x Metal rod
1 x Safety guard
1 x Adjustment screw with rubber buffer (short)
2 x Mounting pieces
2 x Plastic location pieces (mounting pieces)
2 x Fastening screws (vice)
Introduction / Safety advice
1 x Vice adjustment thread (vice)
1 x Rotary adjustment knob (vice)
1 x Guide bolt (vice)
1 x Guide (vice)
1 x Clip
3 x Square nuts (guide rail)
1 x Stop (vice)
1 x Stop (vice rear jaw)
2 x Fastening bolts (vice rear jaw)
2 x Washers (fastening bolts vice rear jaw)
1 x Mounting bolt (guard mount)
1 x Nut (mounting bolt guard mount)
1 x Nut (guard mount)
3 x Distance pieces (60 / 90 / 130 mm)
3 x Washers (mounting bolt)
2 x Plastic bushings M6
2 x Plastic bushings M8

Technical data

©
Max. dimensions of the workpiece:
Tubes: round tube: 30 x 2 mm (ø x t)
other shapes: 30 x 2 mm (W x t)
Bars: round bar: ø 12 mm
other shapes: 12 mm (W)
Plates: 45 x 2 mm (W x t)
Material / Weight:
Material: Aluminium alloy, cast iron (main material)
Weight: 2.I kg (±5%)

Safety advice

WARNING!
Read all the safety advice
and instructions. Failure to observe the safety
advice and instructions could result in electric shock,
fire and/or serious injury.

General safety advice

½
DANGER OF LOSS OF LIFE
AND ACCIDENT TO INFANTS
AND CHILDREN! Never leave
children unsupervised with the packaging materials.
