3. Components Naming

1. Bubble
2. Lock Screw
3. DIP Switch 1
4. DIP Switch 2
5. Camera
6. Lock Holder
7. Power input
FIG.1
8. Video Output
9. Loop RX
10. Loop TX
11. Power LED
12. Aux terminal
13. Alarm terminal
14. Mount Holder
