This tool works at 525°C=1000°F,
without a flame or any visual indication.
Precautions must be taken against the
slight risk of burns.
• Cereless use of this device can cause fire.
• Pay close attention when using the device in places
where combustible materials are to be found. Do not use
it in the same place over a long period of time.
• Do not use the device in an atmosphere where an
explosion could take place.
• Heat can be transmitted to combustible materials
located outside one's field of vision.
• After use, place the device on its holder and let it cool
down before putting it back in place.
• Do not leave this device unattended when not in use.
• If the feeding cable is damaged, have it replaced by
the manufacturer, technical service or another qualified
person in order to prevent possible hazards.
The AG98R manual edgebander can band pre-glued
rolled edges in PVC, polyester, melamine or wood ve-
neer at thicknesses of up to 1 mm, or in pre-cut strips
of up to 2 mm

1. SPECIFICATIONS

Input Power.................................................1.500 W
Equivalent measured continuous
acoustic pressure level A..........................65,6 dB(A)
Normal level of vibrations (hand-arm)..........<2,5m/s
Temperatures..................................I - 300°C=570°F
...................................................II - 525°C=1.000°F
Approximate flow-rate................................400l/min
Maximum edging
width...................50 mm with edge thickness of 1 mm
Maximum edging width................25 mm with edge
thickness of 2-3 mm and pre-cut strip
Weight...........................................................2,8 Kg
PREPARING THE AG98R FOR EDGEBANDING
NARROW EDGES ON A ROLL (max. 1 mm)
2. INSTRUCTIONS FOR HANDLING, ASSEMBLING
AND ADJUSTING THE LOADER
1. Assembly:
Fit the loader in its housing using, screws A, (Fig. 1).
2. Adjustment:
A) Loosen knob B, (Fig. 2), and remove the cover from
the loader D.
B) Adjust the Three rods C to the internal diameter of
the strip roll.
C) Place the pre-glued strip roll in the support, replace
the cover to D and fix it using knob B.
3. ADJUSTING MOVEMENT OF THE STRIP
1. Loosen knobs E, (Fig. 3), and separate the two bodies
to allow the strip to pass.
2. Pass the strip under the anti-return rod F, (Fig. 4), and
through blades U until it is under glueing roller W.
3. Use knob H to adjust the moving part G, (Fig. 3), to
the width of the strip. Do not trap it. When it is guided,
secure it in this position with knobs E, (Fig. 3).
4. ADJUSTING THE CLAMPS
Carry out the adjustments in the order given below:
1. Fixed side:
A) With an overlap: For an overlap of 1.5 mm on this side
for later trimming, place clamp I, (Fig. 5), at the end of
the slotted lever (position furthest away from the fixed
body), and lock it in this position with knob J.
B) Flush with the board: If you wish to glue the edge on
this side, flush with the board, place clamp I at the end of
the fixed side and lock it in this position with knob J.
2. Moving side:
Place the panel between the two clamps. Loosen knob
K, (Fig. 5), and remove mobile clamp G. Place the panel
between the two clamps, bring mobile clamp G up until
the panel is caught between the clamps and fix in this
position with knob K. Then remove the panel; close
moving clamp G by another 2 mm, taking scaled plate
L as a reference, and lock the clamp in this position with
knob K. In this way, the pressure of the leaf springs is
adjusted, and the machine is ready to use.
2
5. OVERLAP DISTRIBUTION
The overlap, or the difference in width between the
panel to be edge banded and the width of the strip
being used, is distributed as follows:
1. Fixed side:
The overlap on this side will be 1.5 mm, or there will be
no overlap, depending on the way the clamp on the fixed
side has been adjusted (see clamps section) (Fig. 5).
2. Moving side:
A) All the overlap will remain on this side of the panel,
if the fixed side clamp I has been adjusted "FLUSH WITH
THE BOARD". (Fig. 5).
B) If the fixed side clamp has been adjusted "WITH AN
OVERLAP", all the overlap except for 1.5 mm (Fig. 5)
will remain.
6. GLUING NARROW EDGES
1. Place the tool at the beginning of the panel, making
sure that the pre-glued strip exceeds the panel end by
at least 1 cm: (Fig. 6).
2. Set the switch to position I or II to start up the heater
and wait for a few seconds until the rated temperature
is reached and the strip glue starts to melt.
