A) Weather trend
After putting the weather station into operation, for ca. 12-24 hours there is no
weather trend data available, since the station first has to gather data.
1. The arrow symbols (5) show the air pressure tendency. In combination with the weather
forecast symbols (14), they show the development of the weather. The arrow aimed
downward points to areas of locally falling air pressure; the one aimed upward points to
rising air pressure. The weather symbols accordingly indicate the weather changes to be
expected.
B) Display of maximum and minimum values
Outdoors
1. Press the "Min/Max" button (B) once to display the maximum values of outside temperature
and (1) and outside air humidity (8).
2. For the temperature values, time and date of recording of these values are also indicated
in the display (1) and (4 & 15). This data does not apply to the recording of the air humidity
values.
. Press the "Min/Max" button (B) twice to display the minimum values of outside temperature
and (1) and outside air humidity (8).
4. For the temperature values, time and date of recording of these values are also indicated in
the display (1) and (4 & 15). This does not apply to the air humidity values.
Indoors
1. Press the "Min/Max" button (B) three times to display the maximum values of inside
temperature (15) and inside air humidity (4).
2. For the temperature values, time and date of recording of these values are also indicated
in the display (1) and (4 & 15). This data does not apply to the recording of the air humidity
values.
. Press the "Min/Max" button (B) 4 times to display the minimum values of inside temperature
and (15) and outside air humidity (4).
4. For the temperature values, time and date of recording of these values are also indicated in
the display (1) and (). This does not apply to the air humidity values.
If necessary, repeat these procedures for the individual outside sensors. Switch to the desired
channel with the "CH" button (A); the current channel number (7) is displayed.
C) Resetting the maximum and minimum values
1. Press the MIN/MAX button (B)  times to display the maximum values of the inside
temperature (1).
2. Press the "SET" button (D) to reset all values, including the recording time or date.
. Pressing the "MIN/MAX" button (B) twice switches back into normal display.
4. Press the "MIN/MAX" button (B) 4 times to display the minimum values of the inside
temperature (1).
6
5. Press the "SET" button (D) now to reset all values, including the recording time or date.
6. Pressing the "SET" button (D) once more switches back into normal display.
D) Display of the max-min outside temperature of the day
• Choose the desired channel number by pressing the "CH" button (A). The maximum and
minimum values of the outside temperature of each channel are indicated in the displays
(10) (11).
The maximum and minimum values of the day's temperature are automatically reset
at 8 p.m. of the same day. A new cycle begins.

8. Mounting

Before permanently mounting the brackets, please place all units in the desired
installation or mounting locations and check whether the outside area data are
correctly received. If this is not the case, then in most cases a slight shift of mounting
locations is sufficient for adequate signal reception.
A) Placement of the base station
The weather station can be installed in free-standing fashion or mounted on a wall. Before
mounting on a wall, make sure that the outside temperature values can be correctly received at
the desired mounting location.
In addition, mount all units in locations where they are sufficiently protected against dampness
and rain.
Free-standing installation
With the help of its stand that can be fastened, the station can be installed on any flat surface.
