INSIDE
Funktionseinstellungen
Controls:
4. Interval control -
flushing automatic
Preset to 24 h
(configurable from 3–48 h).
DIP switch:
Dip switch Function
1 OFF = urinal, ON = washbasin
2 OFF = UR sensor, ON = UR sensor siphon
ON = flushing automatic
3
OFF = dry-out protection
4
Alternative trigger
5 Clog protection
6 Stadium mode
default setting
1)
5. Time control -
flushing time
Preset to 5 s
(configurable from 1–15 s).
6. Time control -
alternative trigger
You can configure an alter-
native flushing trigger for
checking the function and for
clearing out introduced water
by enabling DIP switch 4
(see page 29). If liquid drains
through the sensor odour trap
for the set duration (preset to
2 s, configurable from 2-30 s),
a flushing cycle is triggered.
DIP setting
OFF
1)
ON
1)
ON
1)
ON
1)
OFF
1)
OFF
1)
Urinal control WimTec INSIDE
EN
Description
page 28
page 29
page 29
page 30
23
