Legend - Wimtec Inside Montage- Und Bedienungsanleitung

EN
INSIDE
Steuer-Modul
Legende
1
N N
2
4
5
7 6
ON
OFF
1 2 3 4 5 6
22 Urinal control WimTec INSIDE
L L
8
9
10
Connection 230 V
1
Connection MICRO UR -
2
sensor siphon
Connection magnetic valve
3
Interval control
4
Time control - flushing time
5
3
Time control - alternative trigger
6
DIP switch
7
Connection MICRO sensor
8
Status LED 1
9
Status LED 2
10
