2.10.2 Installing Windows
Vista
If you want to install Windows
your SATA3 HDDs without RAID functions, please follow below steps.
Using SATA3 HDDs without NCQ and Hot Plug functions (IDE mode)
STEP 1: Set up UEFI.
A. Enter UEFI SETUP UTILITY
B. Set the "SATA Mode" option to [IDE].
STEP 2: Install Windows
your system.
Using SATA3 HDDs with NCQ and Hot Plug functions (AHCI mode)
STEP 1: Set up UEFI.
A. Enter UEFI SETUP UTILITY
B. Set the "SATA Mode" option to [AHCI].
STEP 2: Install Windows
your system.
30
®
8 / 8 64-bit / 7 / 7 64-bit / Vista
TM
64-bit Without RAID Functions
®
8 / 8 64-bit / 7 / 7 64-bit / Vista
Advanced screen
®
8 / 8 64-bit / 7 / 7 64-bit / Vista
Advanced screen
®
8 / 8 64-bit / 7 / 7 64-bit / Vista
ASRock 970 Pro3 R2.0 Motherboard
TM
TM TM
/ Vista 64-bit on
Storage Configuration.
TM TM
/ Vista 64-bit OS on
Storage Configuration.
TM TM
/ Vista 64-bit OS on
/
