Clamp-on Ammeter F110
GB
Regulation use of the measuring device comprises:
• Measurement, conversion (Hall effect sensor) and display of
AC currents up to 600 Arms max.
• Measurement of AC voltages up to 600 VACrms max.
• Measurement of resistances up to 199 Ω max. and continuity
check
• Measurements of frequencies up to 2 kHz max.
• Uses other than specified are not permissible
• Operation or use in a damp, wet, explosive environment or
during a thunderstorm is not permissible. Please read the

notes on safety!

Important! Please read carefully!
Please read these operating instructions carefully. In case of
damage, ignoring the operating instructions revokes any possi-
ble claims under the guarantee and we can thus assume no lia-
bility for consequent damage.
Table of Contents
1. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2. Notes on Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
3. Description of Operating Elements . . . . . . . . . . . . . . . . . . . .6
4. Use of the Measuring Device . . . . . . . . . . . . . . . . . . . . . . . .8
5. Making Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
6. Maintenance and Calibration . . . . . . . . . . . . . . . . . . . . . . .17
7. Technical Data and Measurement Tolerances . . . . . . . . . . .17
2

1. Introduction

The clamp-on ammeter can be used with AC currents up to 600 A
max.. The measuring device includes a useful „Hold" function. If
the „Hold" switch is active, the currently measured current value
is „frozen". The following measurements are also possible: AC
voltage measurements with measurement cables up to 200 V or
600 V; resistance measurements, also with measurement cables
up to 200 Ω , and continuity checks with acoustic display for resi-
stances less than 15 Ω; frequency measurements with measure-
ment cables up to 2 kHz max..
The DMM can be used universally both in the hobby and indu-
strial (restricted) sectors, or in schools, etc..
2. Notes on Safety
• The clamp-on ammeter is EMV safety-tested (domestic use)
and meets EG Guidelines 89/336/EWG and 73/23/EWG.
• The Clamp-on ammeter leaves the factory in a technically
safe condition. To maintain this condition and ensure safe
operation, the user must take account of the safety instruc-
tions and warnings contained in these operating instruc-
tions. The manufacturer guarantees satisfaction of the follo-
wing (international) standards: UL 3111, CSA C22.2 No.
1010.1-92, ISA-DC82 and IEC 1010-2-32 (1994).
Page
• The measuring device (clamp-on ammeter without measure-
ment cables) may be used in installations of voltage surge
category III to IEC 664. However, the measurement cables,
are not electric arc explosion-protected (IEC 1010-2-031,
Section 13.101).
• Please note the following symbols:
WARNING! Electric shock if touched!
3
