Technische Daten

( )* = Werkseinstellung
Isolationskoordination nach IEC 60664-1/IEC 60664-3
Definitionen:
Messkreis (IC1) .................................................................................................................................... L1/+, L2/-
Versorgungskreis (IC2)................................................................................................................................A1, A2
Ausgangskreis (IC3)............................................................................................................................... 11, 14, 24
Steuerkreis (IC4) .............................................................................................................................E, KE, T/R, A, B
Bemessungsspannung............................................................................................................................................400 V
Überspannungskategorie ............................................................................................................................................. III
Bemessungs-Stoßspannung:
IC1/( IC2-4 ).................................................................................................................................................... 6 kV
IC2/( IC3-4 ).................................................................................................................................................... 4 kV
IC 3/IC4............................................................................................................................................................ 4 kV
Bemessungs-Isolationsspannung:
IC1/( IC2-4 )..................................................................................................................................................400 V
IC2/( IC3-4 )..................................................................................................................................................250 V
IC 3/IC4..........................................................................................................................................................250 V
Verschmutzungsgrad .................................................................................................................................................... 3
Sichere Trennung (verstärkte Isolierung) zwischen:
IC1/( IC2-4 )...................................................................................................Überspannungskategorie III, 600 V
IC2/( IC3-4 )...................................................................................................Überspannungskategorie III, 300 V
IC 3/IC4...........................................................................................................Überspannungskategorie III, 300 V
Spannungsprüfungen (Stückprüfung) nach IEC 61010-1:
IC2/( IC3-4 )............................................................................................................................................AC 2,2 kV
IC2/IC4.....................................................................................................................................................AC 2,2 kV
Versorgungsspannung
Versorgungsspannung
Toleranz von ....................................................................................................................................... -30...+15 %
s
Frequenzbereich ..................................................................................................................................... 47...63 Hz
s
Eigenverbrauch ...................................................................................................................................... ≤ 3 W, ≤ 9 VA
14
....................................................................................... AC 100...240 V / DC 24...240 V
s
