76
© SICK AG • Industrial Safety Systems • Germany • All rights reserved
Bit 13: 1: reflector detected
Bits 12 ... 0: distance in cm: 0x03E8 = 1000 [cm]
(512 cm + 256 cm + 128 cm + 64 cm + 32 cm + 8 cm = 1000 cm)
E8 23 Measured value 2 in current measuring range (in this case: at 0.25°): 0x23E8,
in bit notation: 0010 0011 1110 1000
Bit 15: 0: no interruption of field C and D (if activated as protective field)
Bit 14: 0: no interruption of field A and B (if activated as protective field)
Bit 13: 1: reflector detected
Bits 12 ... 0: distance in cm: 0x03E8 = 1000 [cm]
E8 23 Measured value 3 in current measuring range (in this case: at 0.5°): 0x23E8,
in bit notation: 0010 0011 1110 1000
Bit 15: 0: no interruption of field C and D (if activated as protective field)
Bit 14: 0: no interruption of field A and B (if activated as protective field)
Bit 13: 1: reflector detected
Bits 12 ... 0: distance in cm: 0x03E8 = 1000 [cm]
E8 03 Measured value 4 in current measuring range (in this case: at 0.75°): 0x03E8,
in bit notation: 0000 0011 1110 1000
Bit 15: 0: no interruption of field C and D (if activated as protective field)
Bit 14: 0: no interruption of field A and B (if activated as protective field)
Bit 13: 0: no reflector detected
Bits 12 ... 0: distance in cm: 0x03E8 = 1000 [cm]
E8 03 Measured value 5 in current measuring range (in this case: at 1°): 0x03E8,
in bit notation: 0000 0011 1110 1000
Bit 15: 0: no interruption of field C and D (if activated as protective field)
Bit 14: 0: no interruption of field A and B (if activated as protective field)
Bit 13: 0: no reflector detected
Bits 12 ... 0: distance in cm: 0x03E8 = 1000 [cm]
E8 23 Measured value 6 in current measuring range (in this case: at 1.25°): 0x23E8,
in bit notation: 0010 0011 1110 1000
Bit 15: 0: no interruption of field C and D (if activated as protective field)
Bit 14: 0: no interruption of field A and B (if activated as protective field)
Bit 13: 1: no reflector detected
Bits 12 ... 0: distance in cm: 0x03E8 = 1000 [cm]
E8 23 Measured value 7 in current measuring range (in this case: at 1.5°): 0x03E8,
in bit notation: 0010 0011 1110 1000
Bit 15: 0: no interruption of field C and D (if activated as protective field)
Bit 14: 0: no interruption of field A and B (if activated as protective field)
Bit 13: 1: no reflector detected
Bits 12 ... 0: distance in cm: 0x03E8 = 1000 [cm]
E8 03 Measured value 8 in current measuring range (in this case: at 1.75°): 0x03E8,
in bit notation: 0000 0011 1110 1000
Bit 15: 0: no interruption of field C and D (if activated as protective field)
Bit 14: 0: no interruption of field A and B (if activated as protective field)
Bit 13: 0: no reflector detected
Bits 12 ... 0: distance in cm: 0x03E8 = 1000 [cm]
22 22 ID for measured data in measuring range 2 (set in CDS, here: 32° to 33°)
E8 03 Measured value 1 in current measuring range (in this case: at 32°): 0x03E8,
in bit notation: 0000 0011 1110 1000
Bit 15: 0: no interruption of field C and D (if activated as protective field)
Telegram Listing CMS
S3000/S300 Expert
8015791/WS20/2012-12-12
Subject to change without notice
