6.4.3 Data format of measured data for configuration "Minimum distance per
measuring range" for S3000 (4 Byte)
Bit 31 ... 29
Status bits
Bit 31: Interruption of field C or D detected (if the
field is activated as a protective field)
Bit 30: Interruption of field A or B detected (if the
field is activated as a protective field)
Bit 29: CMS models: Reflector detected
Non-CMS models: Scanner dazzled
Deviations from this applicable to compatibility
mode:
Bit 31: Measured value detected within
simultaneous protective field
Bit 30: Measured value detected within
protective field
Bit 29: Firmware < B02.40:
Reflector detected or scanner dazzled
(depending on the configuration in
Application config block)
Firmware ≥ B02.40:
Reflector detected
6.4.4 Data format of measured data for configuration "Minimum distance per
measuring range" for S300 (4 Byte)
Bit 31 ... 29
Status bits
Bit 31: Firmware < 2.10: Measured value
detected within warning field
Firmware ≥ 2.10: 0 (fixed bit value)
Bit 30: Measured value detected within
protective field
Bit 29: Reflector detected
© SICK AG • Industrial Safety Systems • Germany • All rights reserved
Bit 28 ... 16 Bit 15 ... 0
Measured Angle from 0° to 190°
distance in
(given in 0.01°)
centimeters
Bit 28 ... 16 Bit 15 ... 0
Measured Angle from 0° to 270°
distance in
(given in 0.01°)
centimeters
