PR 4501 DISPLAY / PROGRAMMING FRONT

Application:
• Communications interface for modification of operational parameters in 4114.
• Can be moved from one 4114 module to another and download the configu-
ration of the first transmitter to subsequent transmitters.
• Fixed display for visualisation of process data and status.
Technical characteristics:
• LCD display with 4 lines; 1 line with the height 5.57 mm, 2 lines with the
height 3.33 mm, and 1 line with fixed icons.
• Programming access can be blocked by assigning a password. The password
is saved in the transmitter in order to ensure a high degree of protection
against unauthorised modifications to the configuration.
Mounting / installation:
• Click 4501 onto the front of 4114.
30 30

Applications

Input signals:
Volt
Potenti-
Current age ometer RTD and lin. R
Connect., wires
+
+
-
-
Output signals:
Supply:
33
21.6...253 VAC
32
or
19.2...300 VDC
31
TC
44
43
42
41
Analogue, 0/4...20 mA and voltage
12
+
-
14
+
10 V 10 V
-
1 V 1 V
13
11
31 31
