General

Available designs

The Fronius Power Package is available in the following designs:
Inverters:
-
-
-
-
-
-
-
Position of the AC outlet:
-
-
Cables:
-
-
-
-
AC overvoltage protection in the AC Combiner:
-
-
CEE service socket in the AC Combiner:
-
-
Fronius Datamanager 2.0 system monitoring:
-
-
Overvoltage protection in the inverters:
-
-
-
48
AC Combiner + 3 Fronius Symo (45 - 60 kW)
AC Combiner + 4 Fronius Symo (60 - 80 kW)
AC Combiner + 5 Fronius Symo (75 - 100 kW)
AC Combiner + 6 Fronius Symo (90 - 120 kW)
AC Combiner + 2 Fronius Eco (50 - 54 kW)
AC Combiner + 3 Fronius Eco (75 - 81 kW)
AC Combiner + 4 Fronius Eco (100 - 108 kW)
AC Combiner with AC outlet on right
AC Combiner with AC outlet on left
without cables
with data communication cables, included
with AC IN cables to the inverters, connected to the AC Combiner
with data communication cables, included, and with AC IN cables to the inverters, con-
nected to the AC Combiner
Number of data communication cables and AC IN cables in line with the number of
inverters in each case.
without overvoltage protection
with overvoltage protection type 1+2+3, built in and connected in the AC Combiner;
with integrated signal line for error messages
without CEE service socket
with CEE service socket, built in and connected in the AC Combiner
without system monitoring
with Fronius Datamanager 2.0 system monitoring, built in and connected in an inverter
without overvoltage protection in the inverters
with type 2 overvoltage protection for single MPTT, built in and connected in each in-
verter present
with type 2 overvoltage protection for multi MPTT, built in and connected in each in-
verter present
