6. ADVANCED INSTALLATION

6.1 Connecting multiple IR receivers

If you want to operate your A/V equipment from multiple rooms, you can
connect up to 6 IR receivers in parallel to the IR module. Cut therefore the
standard connector of the IR receiver and connect it to the SCREW
TERMINAL of the IR module (see paragraph 4.1).

6.2 Extend the cable length of the IR receiver

Only the cables between the IR receiver and the IR module can be extended.
The IR cables with emitter or blaster LEDs cannot be extended. Place the IR
module as close as possible to your A/V equipment and extend the cable
between the IR receiver and the IR module if needed to a maximum of 300
meters with CAT5 cable (or equal). Cut the standard 3.5mm connector off the
IR receiver cable and extend the cable according to the example below.
IR receiver
Red
Black
Yellow
White
IR CONTROL 10™
CAT5 cable IR module
Orange +12VDC
Blue GND
Green STATUS
Brown IR DATA
