5.4 Connecting the IR Module

1. Connect the installed IR extension cables to the 'IR OUT' connector of
the IR Module.
2. Switch only the switches of the IR Module in BLASTER mode if an IR
extension cable with one blaster LED is connected. In any other case,
leave the switch in the EMITTER mode.
NOTE: a wrong choice between the two possibilities can cause damage
to the IR LEDs and they can even become defective.
3. Connect the installed IR receiver cable to the 'IR RCVR' connector of the
IR Module.
4. Connect the power adapter to the '12VDC' connector of the IR Module
and connect it to the mains.

5.5 Perform a function test of the product

1. If the IR Control 10 XTRA™ is properly connected, the light on the IR
receiver flashes if you push a button on the (infrared) remote control and
aim it towards the IR receiver.
2. Close the doors of your cabinet and make sure the A/V equipment
cannot receive an infrared command directly from the remote control.
Otherwise this could lead to operating problems.
3. You can now operate your A/V equipment via the IR Control 10 XTRA™
through the closed cabinet doors!
If the IR Control 10 XTRA is not reacting in a correct way, try experimenting
with the placement of the IR receiver and/or IR extension cables (emitter or
blaster). Placing it somewhere else could give a better result.
