Accessories

3 852 290 Power supply NG DC (100...240V AC to 24 V DC)
3 820 330 Connection cable 5 m (straight connector)
3 820 340 Connection cable 5 m (90° connector)
3 890 640 LED digital display DA 4000-N
3 890 650 LED digital display DA 4000, with 2 set-point relays
3 890 520 LED digital display DA 6000 with 2 set-point relays,
RS232 output, analog output and maximum value storage unit
3 890 530 DA 6000 with RS485
3 834 210 Adjustable mounting support
7

Maintenance

The pyrometer does not have any parts which require regular service, only the
lens has to be kept clean.
The lens can be cleaned with a soft cloth for cleaning glasses or photo objec-
tives.
The Si-lens of the IN 5-DC-PL2 has an anti-reflective coating which appears
slightly colored. Be extremely careful - this layer can easily be rubbed off - this
will greatly affect the measuring results!
8

Appendix

Output current vs. temperature
8
Ext.PL
T [°C] I [mA]
0
20
40
60
80
100 10.00
120 12.00
140 14.00
160 16.00
180 18.00
200 20.00
0.00
2.00
4.00
6.00
8.00
