36 SMOOTH AGILE TRAINER
ASSEMBLY
STEP 16: Assemble the Console
N OTE: BE SURE TO PUSH THE WIR
YOU SECURE TO THE FRAME.
(A) Connect the 8Pin Power Wire-Top (615) to the 8Pin Power Wire-Upper (616)
as show in FIG1.
(B) Assemble the Computer (312) to the Console Suppor
using two M6 x 40mm Screws (509).
(C) Connect the Hand Puls
show in FIG2.
FIG 1
103
FIG 2
312
ES INTO THE CONSOLE BEFORE
e Sensor Wire -Upper (622) to Computer (312) as
615
616
509
622
t Tube (103) and secure
312
509 X2
