32 SMOOTH AGILE TRAINER
ASSEMBLY
STEP 12: Connect the Moving Linkage
(A) Connect the Action Handlebar-Right (109) to the Moving Linkage-Right
(113) and secure using the 12 x 62-M10 x 20mm Bolt (
Spring Washer (510), 12 x 22 x 2mm Washer (515), an d 12 x 18 x 24.5
Sleeve (514) by 6mm Allen Key (D), as show in FIG1.
(B). Repeat the above procedure to as
501), 12 x 2 x 2mm
semble the left side.
109
113
510
501
D
501 X2
510 X2
514 X2
515 X2
D
515
514
515
FIG 1
510
501 514 113
