ASSEMBLY
STEP 15: Assemble the Front Side Panels
NOTE: THERE ARE 2 HOLES IN THE FRAME COMPONENTS THROUGH
WHICH THE INSIDE AND OUTSIDE PLASTIC PA
TO EACHOTHER. USE
CORRECTLY POSITION THE PLASTIC PANELS.
(A) Assemble the Front Side Panel-LL
to the left Upright and secure using one 4 x 12 Screw (512) and three
4 x 19mm Screws (513).
(B) Repeat the above procedure to assemble the right side.
111
513
512
711
712
THESE HOLES AS REFERENCES TO
(709) and Front Side Panel-LR (710)
513
NELS CONNECT
Reference hole1
110
513
Reference hole2
www.smoothfitness.co.uk
512 X2
513 X6
710
513
512
709
