126 D.h.w. temperature
sensor / d.h.w. ther-
mostat
127 D.h.w. charging
temperature boost
128 D.h.w. switching
differential
129 Maximum d.h.w.
charging time
130 Setpoint of le-
gionella function
131 Forced charging
Block "3-position actuator for d.h.w."
132 Flow temperature
boost mixing valve /
heat exchanger
133 Actuator opening
time
134 Actuator closing
time
135 P-band (Xp)
d.h.w.
control
136 Integral action time
(Tn) d.h.w. control
Building Technologies
0
(0...5)
.........................
10 °C
(0...50) °C
...................
8 °C
(1...20) °C
...................
60 min
(--- / 5...250) min
................
--- °C
(--- / 20...100) °C
...................
0
(0 / 1)
.........................
10 °C
(0...50) °C
...................
120 s
(10...873)
......................
120 s
(10...873)
......................
32.0 °C
(1.0...100.0) °C
...................
120 s
(10...873)
......................
74 319 0618 0 a
0 = 1 sensor
1 = 2 sensors
2 = 1 thermostat
3 = 2 thermostats
4 = 1 sensor, with solar d.h.w.
heating
5 = 2 sensors, with solar d.h.w.
heating
Plant types x–5 without solar
charging: setting = 0
Setting --- = function deacti-
vated
Setting --- = function deacti-
vated
0 = none
1 = daily on first release
s
s
s
