15. Voltage Display for Lithium Rechargeable Batteries

The charger can also display the current voltages of the cells of a lithium rechargeable battery.
For this, the rechargeable lithium battery must have a balancer connection that must
be connected to the charger.
Proceed as follows:
• Select the function "LI BATT METER" in the main menu
of the charger with the button "INC" or "DEC".
• Confirm the selection by pressing the "START/ENTER"
button.
Then the voltage display appears.
• Use the buttons "INC" or "DEC" to switch between:
- individual voltages of cells 1 - 6
- overall voltage ("MAIN"), maximum cell voltage ("H")
and minimum cell voltage ("L")
The individual voltage displays depending on the cell number, of course. The example figure
may be a 3-cell LiPo rechargeable battery (or a multiple-cell LiPo rechargeable battery with
defective cells or defective balancer connections).
The display of the maximum cell voltage ("H") and the minimum cell voltage ("L") of all cells
of the connected battery pack shows the difference of the voltage situation of the cells at a
glance.
• You can return to the main menu as usual via the "BATT.TYPE/STOP" button.
PROGRAM SELECT
LI BATT METER
4.19 4.17 4.19 V
0.00 0.00 0.00 V
MAIN 12.55V
H4.191V L4.170V
