6. Eingänge und Kommunikation
6.4
Quelleingänge des DP2K der C-Serie
Position der Quelleingänge
POWER
10 / 100 / 1000 BASE-T
1
2
Abbildung 6-4
Eingänge
1
DVI-D-Eingang, Anschluss A, Single-Link + HDCP
2
DVI-D-Eingang, Anschluss B, Single-Link + HDCP
3
(nur für 2K-Projektoren) SMPTE 292/424-Eingang, Anschluss A (maximale Kabellänge von 30 m zulässig)
4
(nur für 2K-Projektoren) SMPTE 292/424-Eingang, Anschluss B (maximale Kabellänge von 30 m zulässig)
SMPTE
Society of Motion Picture and Television Engineers – eine globale Organisation mit Hauptsitz in den USA, die Stan-
dards für die visuelle Basisband-Kommunikation festlegt. Hierzu gehören sowohl Film- als auch Videostandards.
DVI
Digital Visual Interface is a display interface developed in response to the proliferation of digital flat panel displays.
The digital video connectivity standard that was developed by DDWG (Digital Display Work Group). This connection
standard offers two different connectors: one with 24 pins that handles digital video signals only, and one with 29 pins
that handles both digital and analog video. This standard uses TMDS (Transition Minimized Differential Signal) from
Silicon Image and DDC (Display Data Channel) from VESA (Video Electronics Standards Association).
DVI can be single or dual link.

DVI-Eingangsformate

Eingang
Quellstandard
Single-DVI
VESA (640x480) 60
Single-DVI
VESA (640x480) 72
Single-DVI
VESA (800x600) 60
Single-DVI
VESA (800x600) 72
Single-DVI
VESA
(1024x768)
Single-DVI
VESA
(1024x768)
64
FMT
SW
OS
ICP
STAT
STAT
STAT
DVI INPUT
DVI A
SEL
3
SYNC OK
1
Vertikalfre-
quenz
60
70
USB
OUT
ICP
ALT
STAT
CINEMA
CONT
RS232 IN
3D INTERFACE
GENERAL PURPOSE IN/OUT
DVI B
SEL
SYNC OK
2
Abtastung
Farbraum
Progressiv
RGB
Progressiv
RGB
Progressiv
RGB
Progressiv
RGB
Progressiv
RGB
Progressiv
RGB
USB
IN
SMPTE 292/424 IN
A
B
SEL
SEL
SYNC OK
SYNC OK
PERIPHERAL PORT
3
4
Sampling
4:4:4
4:4:4
4:4:4
4:4:4
4:4:4
4:4:4
R5905050DE DP2K C-SERIES 29/08/2011
Farbtiefe
8 Bit
8 Bit
8 Bit
8 Bit
8 Bit
8 Bit
