5.20 "The Back" (Fig� 35)
Firm back to support positioning (see 647H491 Instructions for Use).
5.21 "The Seat" (Fig� 36)
Seat base with variable setting possibilities to improve positioning (see 647H450 Instructions
for Use).

6 Adjustment / Assembly Instructions

INfORMATION
The following tools are required for repair and maintenance:
• Allen wrenches, sizes 4 mm and 5 mm
• Torx socket wrenches, sizes x 30 (for models from 2007)
• Open-end wrenches, sizes 19 and 24 mm
• Socket wrenches, sizes 10 and 19 mm
• Phillips head screwdriver
• Tyre levers
• Torque wrench
Each wheelchair user has their own ideas regarding the wheelchair type and accessories that are
correct for him / her, as well as the position in the wheelchair and the handling characteristics.
Therefore, the Start wheelchair offers many options that permit the wheelchair to be adapted
according to your requirements. We recommend consulting your dealer or therapist to determine
the correct wheelchair settings for you.
62
35 36
