5.15 Back Upholstery, Adaptable (Fig� 31)
This back upholstery can be adjusted in segments.
5.16 Folding Back (Fig� 32)
The folding back reduces the folding size and facilitates transportation in a car.
5.17 Angle-adjustable Back (Fig� 33)
The design allows to recline the backrest up to an angle of 30 degrees. The pull cable is used
to unlock the adjustable back.
5.18 Spoke Protector (not illustrated)
Protects the fingers from getting caught in the wheel spokes. Also improves the appearance of
the wheelchair.
5.19 Amputation Legrest (Fig� 34)
Allows positioning of residual limbs at different angles. Upon manipulation of the release lever
which is attached to the swivel segment the amputation legrest angle can be adjusted in small
increments.
31
33
32
34
