2.1.2 Manufacturer Specific Profile Area 0x2000-0x5FFF

Index S Name
2A00h 0 DP_output_cont (soll)
2A01h 0 DP_output_ist
2A02h 0 DP_batch_time_stamp
2A03h 0 DP_batch_value
2A04h 0 DP_stroke_len
2A05h 0 DP_niveau
2A10h 0 DP_state
2A11h 0 DP_Control
2A12h 0 DP_Mode
2A20h 0 DP_stroke_max
2A21h 0 DP_metering volume
2A22h 0 DP_measuring_unit
2A30h 0 DP_volume
2A31h 0 DP_stroke_cnt
Name
DP_output_man (ist)
DP_stroke_len
TPDO2
DP_niveau
TPDO3
DP_HMI_flags
TPDO4
DP_Data#1
DP_Data#2
Typ
U16
U16
U16
U16
U8
U8
U16
U8
U8
U16
float
U8
U32
U16
Typ Beschreibung
U16 Pumpenfrequenz (ist)
in %
U8 Hublänge
U8 Füllstand Dosierbe‐
hälter
U32 Dosierpumpe HMI
Flags
U32 Datenpacket #1
U32 Datenpacket #2
Beschreibung
Frequenz in %
(0=100,0%)
Frequenz in %
(0=100,0%)
Time stamp last
received command
Batch Factor
Hublänge
Füllstand Dosierbe‐
hälter
0=out of ctrl,
1=mem, 2=cal,
3=pos/neg
4=ansaug, 5=war‐
nung, 6=errors,
7=stops,
8-11=mode, 12=aux;
13=flow;14=pause,
15=hand/bus
1= batch-mem,
2=setp. pos/neg,
3=calibrated,
4=flowctrl aktiv,
6=Reset
0=halt,1=manual,
2=batch,
max.Hubfrequenz
(Hübe/min)
in 1/Hub (bei 100%
Hub)
0=Liter, 1=Gallon
in ml since last reset
strokes since last
reset
Anhang
Mapping
0x2A0100
0x2A04000
0x2A05000
0x501001
Objects Attr
RPDO1 wr
TPDO1 RO
RPDO2 WO
RPDO2 WO
TPDO1 RO
TPDO2 RO
TPDO1 RO
SDO RW
SDO WO
SDO RO
SDO wr
SDO wr
SDO RO
SDO RO
