Instruction CF-MC Master Controller

1. Introduction

• The Master Controller, CF-MC, is a part of the new trend-setting CF2 wireless
hydronic floor heating control system from Danfoss. Based on 2-way wireless
communication technology CF2 offers high transmission safety, easy wireless
installation, a high level of individual room temperature control, and thus optimal
comfort and improved energy efficiency.
• The system has a variety of beneficial features and easily accessed application
functionalities. This includes a Master Controller, CF-MC, with short-circuit protect-
ed outputs, regulation by ON/OFF or Pulse Width Modulation (PWM) principles,
global standby, separate relays for both pump and boiler control, self-diagnostic
program and error indication, wireless transmission (link) test possibility on each
type of Room Thermostat, easy wireless system access and extended functionality
via the optional Remote Controller, and Repeater Unit for extended wireless range.
2. CF2 System Overview - fig. 1
a) Master Controller, CF-MC
b) Room Thermostats, CF-RS, -RP, -RD and -RF
c) Remote Controller, CF-RC
d) Repeater Unit, CF-RU
e) External Antenna, CF-EA
3. Functional Overview - fig. 2
Menu selection button
Menu LEDs
Output and configuration selection button
OK button
Output LEDs
Output cable fixing
Relays for pump and boiler
Input for heating/cooling (external ON/OFF switch)
Input for global standby (8°C) (external ON/OFF switch)
Power supply (230V)
Front cover release
External antenna connection

4. Mounting

4.1 Wall

• Remove the front cover (fig. 3)
• Mount with screws and wall plugs (fig. 4)

4.2 DIN-Rail

• Mount DIN-rail parts (fig. 5)
• Click on DIN-rail (fig. 6)
• Release from DIN-rail (fig. 7)
Note: The Master Controller should be mounted in an horizontal upright position
5. Installation Procedure (Sequential)
Important Note: Complete all the installations on the Master Controller described below before
connecting to a 230V power supply !
VI.UH.K6.1C
4
Produced by Danfoss Floor Heating Hydronics 03.2007
