6. Technical daTa
6.1.

conformity

In accordance with the Declaration of conformity, the control head Type 8695 is compliant with the EC Directives.
6.2.

standards

Conformity with the EC Directives is verified by the following standards.
EN 61000-6-3, EN 61000-6-2, EN 61010-1
6.3. Operating conditions
Warning!
solar radiation and temperature fluctuations may cause malfunctions or leaks.
• If the device is used outdoors, do not expose it unprotected to the weather conditions.
• Ensure that the permitted ambient temperature does not exceed the maximum value or drop below the mini-
mum value.
Ambient temperature:
Protection class:
6.4. Mechanical data
Dimensions
Body material
Sealing material
Stroke range of valve spindle
12
0 ... +55 °C
IP65 / IP67 according to EN 60529
(only if cables, plugs and sockets have been connected correctly
and in compliance with the exhaust air concept in chapter "8.3. Pneumatic Connection
of the Control Head")
See data sheet
exterior:
interior:
exterior:
21xx series (Element)
and 20xx series (Classic):
Third-party devices:
(modified guide element
required)
english
Type 8695

Technical Data

PPS, PC, VA
PA6; ABS
EPDM / FKM
AS Interface 2 – 25 mm
24 V DC 2 – 35 mm
AS Interface 2 – 34 mm
24 V DC 2 – 44 mm
