10. as inTerface insTallaTiOn
10.1. as interface connection
AS Interface (Actuator Sensor Interface) is a field bus system which is used primarily for networking binary sensors
and actuators (slaves) with a higher-level control (master).
Bus line
Unshielded two-wire line (AS Interface line as AS Interface cable harness) along which both information (data) and
energy (supply voltage for the actuators and sensors) are transmitted.
network topology
Freely selectable within wide limits, i.e. star, tree and line networks are possible. Further details are described in the
AS Interface specification (A/B slave model conforms to the version 3.0 specification).
10.2. Technical data for as interface pcBs
Supply: via AS-Interface (24 V + 20 % / -10 %)
Outputs: 1 Valve Y1, max. 1 W, Power reduction after approx. 100 ms
with integrated Watch-Dog function
Certification: Certificate no. 87301 after version 3.0
10.3. programming data
I/O configuration
ID code
Extended ID code 1
Extended ID code 2
Profile
Table 5:

Programming data

Bit configuration
datenbit
Input
Output
parameter bit
Output
Table 6: Bit configuration
32
B hex
A hex (see below for bit configuration)
7 hex
E hex
S-B.A.E
d3 d2
0 Top not reached 0 Bot not reached
1 Top reached 1 Bot reached
– –
p3 p2
not used not used
english
Type 8695

AS Interface Installation

d1 d0
– –
0 Pilot valve
not used
1 Pilot valve
p1 p0
"0" START Teach function
not used
"1" STOP Teach function
OFF
ON
