HomeMatic HM-CC-TC Montageanleitung Und Bedienungsanleitung Seite 17

Example:
Sensor
HM-Sec-SC (1)
HM-Sec-SC (2)
HM-Sec-RHS
If window 3 is closed however (1 and 2 remain open), it switches
and 3 are closed.
If all windows are indicated as closed, the room control-
ler is set back to the original temperature.
The temperature can be changed at any time, even with the
window open.
As soon as a shutter contact or a window rotary handle
sensor is taught on the room thermostat, it activates the
WAKE-ON-RADIO-MODE so that the even indication that is sent
from the shutter contact or the door window rotary handle sensor
can be received. This results in increased power consumption of
the device and a decrease in the life-span of the battery.
Window 1
Window 2
Window 3
Window-open
temperature
47
