Measuring point installation in bypass, consisting of:
Fig. 12.1
Pos.
Designation
1a
Flow-through housing DN 50
2
Reduction d 50 25 mm concentric, V2A seamless
3
Weld-on sleeve G ½, stainless steel
4
Cutting ring screw coupling G ½ for pipe 12 x 1.5 mm
5
Pipe 12 x 1.5 mm, stainless steel
6
Spherical stop valve G ½, stainless steel
7
Double nipple G ½, stainless steel
8
Teflon sealing tape (roll)
417102012_LMI02.doc
- 92 -
Part
Item no.
1
287507
2
415508873
4
415203424
4
415101885
4
415031164
2
415502024
2
415203604
1
417100813
Rev. 10-01.09
