4. Installation and commissioning

To avoid the risk of accidental start, disconnect the spark boot plug.
4.1 Combined gasoline grass trimmer, pole saw, brush cutter: drive unit
Part 1:
1
A6
4.2 Combined gasoline grass trimmer, pole saw, brush cutter: grass trimmer
INJURY WARNING: Always wear protective gloves when working on or around cutting
tools.
Part 2:
15
18
50
mounting:
Attach the handle
12
(1) with the four
fixing screws (12)
and the nuts of the
28
protective device
(18) to the drive
unit
18
Mounting:
To use the unit as a grass trimmer,
the cutting guard (15) and line
spool (18) must be attached.
28
1
15
19
