d. "PCB CONTROL" Mechanical Adjustment of the Speed of the
Upper and Lower Rotor Blades (blade rotation)
* Motor 2
GB
Power wire
* Servo 2
* Servo 1
Light socket
Warning!!!
Please work very carefully, applying minimal pressure and using a
small screwdriver.
1. Function of the adjustment screw: Adjusts the difference between
the blade rotations of the upper and lower rotor blades.
a. If the screw is turned clockwise, the lower rotor blades turn
faster and the helicopter veers towards the right.
e. Swashplate Adjustment
If your helicopter doesn't hover smoothly in one spot even after
adjusting by means of the trim lever on the transmitter, the swashplate
should be adjusted as follows:
1. Check the swashplate: Connect the battery to the helicopter and
switch on the transmitter. After connecting the RC unit the gas stick
must be set to minimum. Set the trim lever for nick and roll to the
middle position. Now check whether the swashplate is in the
horizontal position.
2. Adjusting the swashplate: If the swashplate is not in the horizontal
position, it should be adjusted as follows:
90°
30 CARSON Mini Tyrann
Motor 1
b. If the screw is turned anti-clockwise, the upper rotor blades turn
faster and the helicopter veers towards the left.
2. The "PCB CONTROL" is correctly adjusted when the helicopter stops
drifting in either direction.
a. Uncouple the linkage from the swashplate (unclamp the ball socket
from the swashplate).
b. Turn the ball socket clockwise or anti-clockwise to adjust the length
of the linkage.
After adjustment, the swashplate should be in a horizontal position.
(See illustration)
c. Then carefully press the ball socket onto the ball head again.
90°
L R Antenna
Ball head buckle
Linkage
