InItIaL operatIon oF tHe SpeeD controLLer

1. Switch on the transmitter and check the path of the throttle
channel, which should be 100% in both directions.
The throttle must be in the "Motor off" position! The neutral
position and the throttle positions of the speed controller are
pre-programmed and may only be changed via the transmitter
by readjusting the trim positions/lever and the servo travel.
2. Connect the drive battery with the correct polarity to the speed
controller.
3. Now switch on the speed controller.
Warning!
• if the speed controller is switched on, you must pay attention to
the motor and speed controller. Do not touch the motor shaft,
ship's propeller and rotating parts. There is a risk of injury in
doing so. Ensure that the motor shaft is not blocked and does
not drag.
• Always switch the controller off after use and do not leave your
model unattended.
• Ensure that all the connections and cables are correctly routed
and connected.
• Avoid connecting incorrectly, short circuiting and reversing
polarity.

InStaLLIng tHe eLectronIcS

After connecting the RC assembly, the components can be positioned in the body. Position them on a clear, flat surface. It is recom-
mended that you use hook and loop tape.

baLancIng tHe HuLL

Check the balance of the water line repeatedly. To do this, place the boat in the water and check whether the hull lies evenly in the water.
If the balance is not yet perfect, you can move the battery again and replace it in a new position. Repeat this process until the boat is
perfectly balanced. If necessary, use additional lead weights, etc.

aSSembLIng tHe aDD-on partS

Among other thing, your boat is supplied with other add-on parts such as masts, rigging and small items. etc. Please remove them care-
fully from the packaging and assemble them using a little adhesive as can be seen in the cover picture on the packaging. Alternatively,
insert the hooks of the rigging into the eyes installed in the deck/hull.
4. The speed controller is now ready to use and all set for its first
trip.
5. To move forwards, push the throttle stick of your remote
forwards. To move backwards, pull it back. If this does not apply
because the function is reversed, you must reset the reverse
switch of the throttle channel.
6. After use, first the speed controller must be switched off and
then the drive battery connector detached from the speed
controller.
• Keep out of the reach of children.
• Do not expose the unit to direct sunlight.
• The speed controller has a temperature sensor to protect it
from overheating. A good supply of cool air must be ensured;
otherwise, the controller will switch off.
• Motor and controller heat up during operation. Please allow the
components to cool down before storing or reusing.
17 // Gb
