c. Four Channel Remote Control Transmitter
Included in the scope of delivery is a remote control transmitter with delivery is a remote control transmitter with
two remote control levers, which are assigned the four respective s, which are assigned the four respective
functions.
These functions are activated by the movements forwards / ated by the movements forwards /
backwards and right / left. t.
AA X 8 batteries are required are required
for the transmitter mitte e r er
CH3 throttle
Trim adjustment
Ascend
Turn Turn
left right
Decline
CH4 tail rotor function
Trim adjustment
LED indicator
Functions on the back of
the transmitter:
• Charging socket
• Battery chamber
Battery cover
Put the charged batteries in the battery Put the charged batteries in the battery compartment of the
transmitter. transmitter.
Pay attention to the correct polarity! Pay attention to the correct polarity!
Antenna
CARSON Mini Tyrann
"Mode 2"
left control lever:
throttle
Hook for
carrying strap
CH2 elevator
Trim adjustment
Elevator front
Roll Roll
(aileron) (aileron)
left right
Elevator rear
CH1 Roll (aileron)
Trim adjustment
Power switch
Reverse switch CH4 tail function
Reverse switch CH3 throttle
Reverse switch CH2 elevator
Reverse switch CH1 roll (aileron)
Charging port
