Instruction Manual DIGIMON-SE / DIGIMON4
Property
Maximum working
pressure:
Pressure
resolution:
Pressure units:
Positive pressure
display:
Negative pressure
display:
Accuracy class:
External
thermocouple:
Optional clamp
thermocouple K-
type
Ambient
temperature:
Power supply:
Storage
temperature:
Vacuum display without vacuum sensor
Property
Vacuum display:
Value
Low pressure: 60bar / 870psi / 6000kPa / 6MPa
High pressure : 60bar / 870psi / 6000kPa / 6MPa
0.01 bar / 0.5psi / 1kPa / 0.001MPa
bar / psi / kPa / MPa
0 to 60bar, up to 870psi, up to 6000kPa, up to 6MPa
0 to -0.95bar, 0 to -13.7psi, 0 to -95kPa, 0 to -0.095MPa
Class 1.0
Temperature range:
Plug:
Accuracy of
measurement:
Resolution:
Temperature range:
For pipe diameters of:
Plug:
Accuracy of
measurement:
Resolution:
0°C to +50°C / +32°F to +122°
4 x 1.5 V AA / Mignon / LR6 batteries
Service life of approx. 50 hours when used continuously.
- 20°C to + 60°C / -4°F to 140°F
Value
Bar diagram display
-40°C to +125°C / -40°F to +257°F
K-type
+/- 1°K
0.1°C / 0.1°F
-40°C to +125°C / -40°F to +257°F
6mm to 38mm / ¼" to 1 ½"
K-type
+/- 1°K
0.1°C / 0.1°F
1 bar ca. 0 to -300mbar
2 bars ca. -300 to -380mbar
3 bars ca. -380 to -460mbar
4 bars ca. -460 to -540mbar
5 bars ca. -540 to -620mbar
6 bars ca. -620 to -700mbar
7 bars ca. -700 to -780mbar
8 bars ca. -780 to -860mbar
9 bars ca. -860 to -920mbar
10 bars ca. -920 to ultimate vacuum
