17 Connections diagram

Power Rail
connections
91 92 93 94 95
Gnd.
error signal +24 V
Nc = no connection
RtD, 2-wire
41 42 43 44
Resistance, 2-wire
41 42 43 44
2-wire transmitter
51 52 53 54
+
-
tx
current
(active output)
11 12 13 14
+
- ma
9116 UNiVeRsal coNVeRteR
Nc Nc
Inputs:
RtD, 3- / 4-wire
41 42 43 44
Resistance,
3- / 4-wire
41 42 43 44
current
51 52 53 54
+
-
Outputs:
2-wire transmitter
(Passive output)
11 12 13 14
+ ma
Version No. V1R0
supply and
status relay
31 32 33 34
N.c.
Gnd.
+24 V
tc, internal cJc
sensor
41 42 43 44
+
-
Potentiometer
41 42 43 44
1 3
2
Voltage
51 52 53 54
+
-
Relay
11 12 13 14
N.o.
safety Manual
*tc,
cJc connector
41 42 44
cJc
+
-
* order separately:
cJc connector
5910ex.
