action
29 Verify relay activation direction and press oK
(oNlY if Rel.FUN = setP)
30 Verify relay setpoint hysteresis and press oK
(oNlY if Rel.FUN = setP or WiND)
31 Verify relay action on sensor error and press oK
(oNlY if Rel.FUN = setP, WiND or eRR and the
selected input type and range support sensor error
detection, refer to section 4.3.2)
32 Verify relay oN delay and press oK
(oNlY if Rel.FUN = setP or WiND)
33 Verify relay oFF delay and press oK
(oNlY if Rel.FUN = setP or WiND)
34 Verify fixed output range for current output
35 Verify fixed output value on detected sensor error
and press oK
(oNlY if iN.tYPe ≠ Volt, or iN.tYPe = cURR and
i.RaNGe ≠ 0-20 ma)
36 Verify temperature for 0% output and press oK
(oNlY if iN.tYPe = teMP)
37 Verify temperature for 100% output and press oK
(oNlY if iN.tYPe = teMP)
38 Verify analogue output response time and press oK cH1.cal
39 Verify the use of applied process calibration values
and press oK
40 Verify password and press oK
41 Verify sil mode within 1 second
9116 UNiVeRsal coNVeRteR
Version No. V1R0
Display shows
HYst
eRR.act
oN.Del
oFF.Del
o.RaNGe
oUt.eRR
oUt.lo
oUt.Hi
ResP
PassW.
sil.oK
safety Manual
19
