9116 UNiVeRsal coNVeRteR
action
Verify cJc type and press oK
(oNlY if iN.tYPe = teMP and seNsoR = tc)
Verify fixed input voltage range and press oK
(oNlY if iN.tYPe = Volt)
Verify input resistance 0% range and press oK
(oNlY if iN.tYPe = liN.R)
Verify input resistance 100% range and press oK
(oNlY if iN.tYPe = liN.R)
Verify display units for 4501 and press oK
(oNlY if iN.tYPe ≠ teMP)
Verify display decimal point for 4501 and press oK
(oNlY if iN.tYPe ≠ teMP)
Verify display value for 4501 at 0% input and
press oK
(oNlY if iN.tYPe ≠ teMP)
Verify display value for 4501 at 100% input and
press oK
(oNlY if iN.tYPe ≠ teMP)
Verify relay setpoint units and press oK
(oNlY if iN.tYPe ≠ teMP)
Verify relay function and press oK
Verify relay contact function and press oK
(oNlY if Rel.FUN ≠ oFF or PoW)
Verify relay setpoint and press oK
(oNlY if Rel.FUN = setP)
Verify low setpoint value and press oK
(oNlY if Rel.FUN = WiND)
Verify high setpoint value and press oK
(oNlY if Rel.FUN = WiND)
Version No. V1R0
Display shows
V.RaNGe
R 0%
R 100%
UNit
Dec.P
DisP.lo
DisP.Hi
Rel.UNi
Rel.FUN
coNtac.
setP.
setP.lo
setP.Hi
act.DiR
