PR Elecronics 9116 Handbuch Seite 152

LERBAKKEN 10, 8410 ROENDE DENMARK
Module 9116B1
Terminal 51-52, 51-53
Ui, Vmax 30 V
Ii, Imax 120 mA
Pi 900 mW
Ci 3 nF
Li 1 μH
Module 9116B1
Group
Terminal 51-54, 52-54
Uo, Voc 28 V
IIC or A,B
Io, Isc 93 mA
IIB or C,E,F
Po 650 mW
IIA or D,G
Module 9116B1
Group
Terminal 51-53
Uo, Voc 28 V
IIC or A,B
Io, Isc 1.1 mA
IIB or C,E,F
Po 8 mW
IIA or D,G
Module 9116B1
Group
Terminal 51-52
Uo, Voc 8.3 V
IIC or A,B
Io, Isc 0.2 mA
IIB or C,E,F
Po 0.4 mW
IIA or D,G
Module 9116B1
Group
Terminal 41,42,43,44
Uo, Voc 8.3 V
IIC or A,B
Io, Isc 13.1 mA
IIB or C,E,F
Po 27.3 mW
IIA or D,G
Installation notes:
1) The installation shall be in accordance with the National Electrical Code NFPA 70, Article 500 or
505.
2) For installation in Zone 2 or Division 2, the module must be installed in a suitable outer enclosure
having an IP protection of at least IP54.
3) The module is galvanically isolated and does not require grounding.
4) Install in pollution degree 2 or better.
5) Use 60 / 75 ºC copper conductors with wire size AWG: (26-14).
6) Warning: Substitution of components may impair intrinsic safety.
7) Warning: To prevent ignition of the explosive atmospheres, disconnect power before servicing and
do not separate connectors when energized and an explosive gas mixture is present.
8) In type of protection "intrinsic safety iD" the parameters for intrinsic safety for gas group IIB are
applicable.
9) Warning: Do not mount or remove modules from the Power Rail when an explosive gas mixture is
present.
Revision date:
2010-02-12
Co Lo Lo/Ro
80 nF 4 mH 54 μH/Ω
640 nF 16 mH 218 μH/Ω
2.1 μF 32 mH 436 μH/Ω
Co Lo Lo/Ro
80 nF 1000 mH 4 mH/Ω
640 nF 1000 mH 17 mH/Ω
2.1 μF 1000 mH 35 mH/Ω
Co Lo Lo/Ro
7 μF 1000 mH 100 mH/Ω
73 μF 1000 mH 400 mH/Ω
1000 μF 1000 mH 800 mH/Ω
Co Lo Lo/Ro
7 μF 207 mH 1 mH/Ω
73 μF 828 mH 5 mH/Ω
1000 μF 1000 mH 10 mH/Ω
Version Revision
V5 R0
Module 9116B2
Terminal 51-52, 51-53
Ui, Vmax 30 V
Ii, Imax 120 mA
Pi 900 mW
Ci 3 nF
Li 1 μH
Module 9116B2
Group
Terminal 51-54, 52-54
Uo, Voc 21.4 V
IIC or A,B
Io, Isc 93 mA
IIB or C,E,F
Po 650 mW
IIA or D,G
Module 9116B2
Group
Terminal 51-53
Uo, Voc 21.4 V
IIC or A,B
Io, Isc 1.1 mA
IIB or C,E,F
Po 8 mW
IIA or D,G
Module 9116B2
Group
Terminal 51-52
Uo, Voc 8.3 V
IIC or A,B
Io, Isc 0.2 mA
IIB or C,E,F
Po 0.4 mW
IIA or D,G
Module 9116B2
Group
Terminal 41,42,43,44
Uo, Voc 8.3 V
IIC or A,B
Io, Isc 13.1 mA
IIB or C,E,F
Po 27.3 mW
IIA or D,G
Prepared by:
PB
9116QF01
Co Lo Lo/Ro
0.16 μF 4 mH 54 μH/Ω
1.13 μF 16 mH 218 μH/Ω
4.15 μF 32 mH 436 μH/Ω
Co Lo Lo/Ro
0.16 μF 1000 mH 4 mH/Ω
1.13 μF 1000 mH 17 mH/Ω
4.15 μF 1000 mH 35 mH/Ω
Co Lo Lo/Ro
7 μF 1000 mH 100 mH/Ω
73 μF 1000 mH 400 mH/Ω
1000 μF 1000 mH 800 mH/Ω
Co Lo Lo/Ro
7 μF 207 mH 1 mH/Ω
73 μF 828 mH 5 mH/Ω
1000 μF 1000 mH 10 mH/Ω
Page:
2/4
